Three Phase Pad Mounted Transformer | 75–2500 kVA

Key Specifications

A pad-mounted transformer is a ground-mounted, tamper-resistant distribution transformer housed in a locked steel cabinet, designed to supply power safely in areas accessible to the public. CHBEB three-phase pad-mounted transformers are widely used in high-reliability applications such as subway stations, airports, hospitals, data centers and solar power plants. Our products are mainly supplied to the United States, East Asia and Southeast Asia, and OEM/ODM services are available.

About Our Pad-Mounted Transformers

• Integrated design: Based on an oil-immersed transformer, the pad-mounted transformer integrates fuses, tap changers, load-break switches and low-voltage distribution equipment into one compact enclosure. It is available for 50/60 Hz systems, voltages up to 35 kV and standard ratings from 75 kVA to 3,000 kVA.
• High efficiency, lower cost: Efficiency exceeds 99% and complies with DOE 2016 energy efficiency rules, extending service life and reducing total cost of ownership.
• Maintenance-free operation: The IP54 / NEMA 3R enclosure protects against dust and moisture, with a design life of more than 25 years.
• Eco-friendly and sustainable: Compatible with FR3 natural ester (vegetable) insulating oil, which is more than 95% biodegradable.
• Standards and certifications: Designed to ANSI, IEEE C57 and IEC 60076 standards, with ISO, CE, IEC, CSA and UL certifications.

Applications

• Industrial: Power distribution for medium-sized factories and logistics parks.
• Commercial and critical facilities: Main and backup power for commercial sites, hospitals and data centers.
• Urban distribution: Underground-fed power supply for residential communities and urban networks.
• Renewable energy: Grid connection for photovoltaic and energy storage projects.
• Public areas: Safe, tamper-resistant power supply for parks, campuses, streets and other public spaces.

Technical Parameters

HV options: 34.5 kV, 19.92 kV, 13.8 kV, 13.2 kV, 12.47 kV, 7.62 kV, 7.2 kV
LV options: 240 V, 480 V, 480Y/277 V, 600Y/347 V

Customization and Types

The parameters above are standard ratings and can be customized according to project requirements, including voltage ratings, taps, winding material, fusing and protection configuration. The same design principle also applies to other variants, such as photovoltaic step-up, loop-feed (ring network) and radial-feed (terminal) pad-mounted transformers.

Contact Us

Looking for a reliable pad-mounted transformer for your project? CHBEB supplies three-phase pad-mounted transformers in a wide range of ratings, with standard designs and customized solutions available. Browse our CHBEB pad mounted transformers or contact our team today with your voltage, capacity and installation requirements to get a fast quote and professional technical support.
